Electric fixed ball valve
The Electric Fixed Ball Valve is a high-performance automated valve designed for reliable flow control and shut-off in industrial pipeline systems. It features a trunnion-mounted fixed ball structure combined with an electric actuator, providing stable operation, excellent sealing performance, and long service life under high-pressure and large-diameter applications.
Unlike floating ball valves, the fixed ball design uses upper and lower stem supports to reduce operating torque and improve mechanical stability, making it ideal for demanding applications involving high pressure, large flow rates, and continuous operation.
Equipped with an electric actuator, the valve enables remote automatic control, precise positioning, and integration with industrial control systems such as PLC and DCS. It is widely used in oil & gas, petrochemical, power generation, chemical processing, and other industries requiring safe isolation, automated operation, and reliable pipeline control.
Electric fixed ball valve
We provide professional OEM manufacturing and customized solutions according to customer requirements, including:
Our Electric Fixed Ball Valves are manufactured under strict quality control systems and comply with international valve industry standards, including:
Parameter Specifications
| Parameter | Specification |
|---|---|
| Product Name | Electric Fixed Ball Valve |
| Valve Type | Trunnion Mounted Fixed Ball Valve with Electric Actuator |
| Valve Structure | Fixed Ball / Trunnion Mounted Design |
| Nominal Size | DN50 – DN1200 (Customized Available) |
| Pressure Rating | PN16 – PN420 / Class 150 – Class 2500 |
| Connection Type | Flanged, Butt Weld, Customized |
| Valve Body Material | Carbon Steel, Stainless Steel, Alloy Steel, Duplex Steel |
| Ball Material | Stainless Steel, Alloy Steel, Hardened Materials |
| Stem Material | Stainless Steel / Special Alloy |
| Seat Material | PTFE, RPTFE, PEEK, Metal Seat, Graphite |
| Actuator Type | Electric Actuator |
| Operation Mode | On-Off Control / Modulating Control |
| Power Supply | AC220V / AC380V / DC24V (Customized Available) |
| Control Method | PLC / DCS / Remote Control |
| Operating Temperature | -196°C to +500°C (Depending on Materials) |
| Applicable Media | Oil, Gas, Water, Steam, Chemical Fluids, Slurry |
| Leakage Class | ANSI Class V / VI / Bubble Tight Shut-off |
| Flow Bore | Full Bore / Reduced Bore |
| Design Standard | API 6D / ASME B16.34 / API 608 |
| Pressure Test Standard | API 598 / EN 12266 |
| Flange Standard | ANSI B16.5, ASME B16.47, EN1092, JIS, GB/T |
| Anti-Static Design | Available |
| Blowout Proof Stem | Available |
| Double Block & Bleed Function | Optional |
| Fire Safe Design | API 607 / ISO 10497 Optional |
| Explosion-Proof Actuator | Optional |
| Communication Interface | Modbus / Profibus / HART / Fieldbus Optional |
| Manual Override | Available |
| Corrosion Protection | Coating / Special Surface Treatment |
| Certification | ISO, API, CE, ATEX, IECEx, SIL, Fire Safe |
| OEM Service | Available |
Industry Applications
✔ High-pressure and large-diameter application capability
✔ Low operating torque with trunnion-mounted design
✔ Excellent sealing performance
✔ Long service life under continuous operation
✔ Remote automatic electric control
✔ Suitable for critical pipeline systems
✔ Multiple actuator and material options
✔ Supports intelligent control integration
✔ Full OEM customization capability
✔ Compliance with international valve standards
Material customization plan
Customized 316L stainless steel valves forGerman chemical enterprises. Resistant tostrong corrosion, suitable for their acidicmedium transportation systems, with aservice life extended to over 8 years.
Structural optimization design
For the Saudi desert project, the valve stemsealing structure was changed to a doublebellows design to address the leakage issuein the high-temperature and dustyenvironment, and it was highly recognizedby the customers.
Interface standard adaptation
Customized API 600 standard valves for acertain company in the United States. Theflange size is fully compatible with ANSIB16.5, ensuring zero error during on-siteinstallation and reducing the constructionperiod by 30%.
