Electric high performance butterfly valve
The Electric High Performance Butterfly Valve is an advanced flow control solution designed for industrial applications requiring precise regulation, reliable shut-off, and long-term operational stability. Featuring a high-performance double eccentric or triple eccentric butterfly design, this valve provides excellent sealing performance, low operating torque, and extended service life under high-pressure and high-temperature conditions.
Equipped with a high-quality electric actuator, the valve enables automated operation, remote control, and intelligent process management. It is widely used in industrial pipelines for liquid, gas, steam, and other process media where accurate flow control and reliable automation are required.
Our company offers comprehensive OEM and customization services, including valve size, pressure class, material selection, actuator configuration, control system integration, and special design requirements. All products are manufactured according to strict quality management systems with complete valve industry certifications to ensure safety, reliability, and global application compatibility.
Electric high performance butterfly valve
We provide professional OEM/ODM manufacturing solutions to meet different industrial requirements:
Parameter Specifications
| Parameter | Specification |
|---|---|
| Product Name | Electric High Performance Butterfly Valve |
| Valve Type | High Performance Butterfly Valve |
| Design Type | Double Eccentric / Triple Eccentric Design |
| Operation Method | Electric Actuator |
| Nominal Size | DN50 – DN2000 (Customized Available) |
| Pressure Rating | PN10 / PN16 / PN25 / Class 150-600 |
| Body Material | Carbon Steel / Stainless Steel / Ductile Iron / Customized |
| Disc Material | Stainless Steel / Carbon Steel / Alloy Material |
| Stem Material | Stainless Steel |
| Seat Material | PTFE / Metal Seat / EPDM / Customized |
| Applicable Medium | Water, Oil, Gas, Steam, Chemical Fluids |
| Working Temperature | -40°C to +450°C (According to Material & Design) |
| Connection Type | Wafer / Lug / Flanged |
| Electric Actuator Type | On-Off / Modulating / Intelligent Control |
| Power Supply | AC24V / AC110V / AC220V / AC380V / Customized |
| Control Signal | On-Off / 4-20mA / Fieldbus Communication |
| Protection Class | IP65 / IP67 / IP68 |
| Sealing Performance | Bubble Tight Shutoff |
| Leakage Standard | ISO 5208 / API 598 / EN 12266 |
| Flow Regulation | Precise Flow Control |
| Installation Position | Horizontal or Vertical Installation |
| Surface Treatment | Epoxy Coating / Anti-corrosion Coating / Customized |
| Testing Standard | Pressure Test, Leakage Test, Functional Test |
| OEM Service | Design, Logo, Packaging, Structure Customization |
| Certifications | ISO / CE / API / International Valve Industry Standards |
Industry Applications
The Electric High Performance Butterfly Valve is widely applied in industries requiring automated and reliable flow control:
Material customization plan
Customized 316L stainless steel valves forGerman chemical enterprises. Resistant tostrong corrosion, suitable for their acidicmedium transportation systems, with aservice life extended to over 8 years.
Structural optimization design
For the Saudi desert project, the valve stemsealing structure was changed to a doublebellows design to address the leakage issuein the high-temperature and dustyenvironment, and it was highly recognizedby the customers.
Interface standard adaptation
Customized API 600 standard valves for acertain company in the United States. Theflange size is fully compatible with ANSIB16.5, ensuring zero error during on-siteinstallation and reducing the constructionperiod by 30%.
