Clamp type high-pressure flat gate valve
The Clamp Type High-Pressure Flat Gate Valve is engineered for high-pressure applications in oil, gas, chemical, and industrial pipelines. Its clamp-style body enables rapid assembly and maintenance while maintaining structural integrity. The full-bore flat gate design ensures low pressure loss, tight bi-directional sealing, and reliable operation under extreme conditions.
Clamp type high-pressure flat gate valve
The Clamp Type High-Pressure Flat Gate Valve features a robust clamp-style body construction for high-pressure service. The full-bore flat gate design provides unrestricted flow and minimal pressure drop. This valve type allows quick maintenance without compromising strength or safety, making it ideal for high-pressure industrial, oilfield, and chemical pipelines.
Manufactured from carbon steel, stainless steel, or alloy steel, the valve exhibits excellent corrosion resistance and durability. Manual, electric, pneumatic, or hydraulic operation can be provided for automation purposes.
Clamp type high-pressure flat gate valve
| Parameter | Specification |
|---|---|
| Product Name | Clamp Type High-Pressure Flat Gate Valve |
| Nominal Size | DN50 – DN1200 (2" – 48") |
| Pressure Rating | PN16 – PN420 |
| ANSI Class | Class 150 – Class 2500 |
| Body Material | Carbon Steel, Stainless Steel, Alloy Steel, Forged Steel |
| Gate Material | Stainless Steel, Alloy Steel |
| Seat Material | Soft Seat / Metal Seat |
| Connection Type | Clamp, Flanged, Butt Welded |
| Operation | Manual, Electric, Pneumatic, Hydraulic |
| Temperature Range | -46°C to +550°C |
| Sealing Type | Bi-directional Sealing |
| Leakage Standard | API 598 / ISO 5208 Class A |
| Design Standard | API 6D, API 600, ASME B16.34 |
| Applicable Media | Oil, Gas, Water, Steam, Chemicals |
Clamp type high-pressure flat gate valve
Used in high-pressure transmission, gathering, and refinery pipelines for reliable isolation.
Applied in high-pressure process pipelines, chemical transportation, and industrial utilities.
Suitable for high-pressure water injection, cooling, and steam pipelines.
Ideal for mining, metallurgy, marine, and industrial fluid systems.
Used in injection lines, booster stations, and high-pressure water flooding pipelines.
Material customization plan
Customized 316L stainless steel valves forGerman chemical enterprises. Resistant tostrong corrosion, suitable for their acidicmedium transportation systems, with aservice life extended to over 8 years.
Structural optimization design
For the Saudi desert project, the valve stemsealing structure was changed to a doublebellows design to address the leakage issuein the high-temperature and dustyenvironment, and it was highly recognizedby the customers.
Interface standard adaptation
Customized API 600 standard valves for acertain company in the United States. Theflange size is fully compatible with ANSIB16.5, ensuring zero error during on-siteinstallation and reducing the constructionperiod by 30%.
