Forged steel flanged gate valve for power station
Manufactured from premium forged steel materials, this flanged gate valve is designed for demanding power station applications involving steam, condensate, and high-temperature fluids. Featuring superior mechanical strength, excellent sealing capability, low pressure loss, and long service life, it provides dependable operation in critical energy infrastructure systems.
Forged steel flanged gate valve for power station
The Forged Steel Flanged Gate Valve for Power Station is specifically engineered for thermal power plants, combined-cycle power facilities, nuclear auxiliary systems, and industrial energy projects. Constructed using high-quality forged steel materials, the valve offers exceptional structural integrity and resistance to high-pressure and high-temperature operating conditions.
Its flanged connection design facilitates installation and maintenance while ensuring secure and leak-free operation. The precision-machined wedge gate and hard-faced sealing surfaces provide excellent shut-off performance for critical steam and water systems.
Our Forged Steel Flanged Gate Valves for Power Stations can be supplied with complete international certifications:
Forged steel flanged gate valve for power station
| Parameter | Specification |
|---|---|
| Product Name | Forged Steel Flanged Gate Valve for Power Station |
| Valve Type | Forged Steel Gate Valve |
| Design Standard | API 602 / ASME B16.34 |
| Testing Standard | API 598 |
| Size Range | DN15–DN300 (1/2"–12") |
| Pressure Rating | Class 150, 300, 600, 900, 1500, 2500 |
| Body Material | A105, LF2, F11, F22, F91 |
| Trim Material | 13Cr, SS304, SS316, Stellite |
| Connection Type | Flanged RF / RTJ |
| Bonnet Type | Bolted Bonnet, Pressure Seal Bonnet |
| Operation | Manual, Gear, Electric, Pneumatic |
| Working Temperature | -29°C to 650°C |
| Applicable Media | Steam, Condensate, Feedwater, Thermal Oil |
| Leakage Standard | API 598 |
| Fire Safe Option | API 607 |
| Certification | API, ISO, CE, PED, NACE |
Forged steel flanged gate valve for power station
Used in main steam, reheater, condensate, and feedwater systems requiring reliable shut-off performance.
Suitable for gas turbine auxiliary systems, heat recovery steam generators (HRSG), and steam circuits.
Applied in non-safety-related high-pressure fluid handling systems.
Provides dependable isolation for boiler feedwater and superheated steam pipelines.
Widely used in captive power plants and industrial utility systems.
Suitable for high-temperature steam distribution and process utility applications.
Used in thermal energy transmission systems requiring durable isolation valves.
Material customization plan
Customized 316L stainless steel valves forGerman chemical enterprises. Resistant tostrong corrosion, suitable for their acidicmedium transportation systems, with aservice life extended to over 8 years.
Structural optimization design
For the Saudi desert project, the valve stemsealing structure was changed to a doublebellows design to address the leakage issuein the high-temperature and dustyenvironment, and it was highly recognizedby the customers.
Interface standard adaptation
Customized API 600 standard valves for acertain company in the United States. Theflange size is fully compatible with ANSIB16.5, ensuring zero error during on-siteinstallation and reducing the constructionperiod by 30%.
