Manual bottom discharge valve
The Manual Bottom Discharge Valve is designed for safe and efficient discharge of liquids, slurries, and process media from reactors, tanks, and vessels. Operated by a handwheel, it offers precise control, excellent sealing performance, and minimal residue retention. Its robust construction ensures reliable operation in demanding industrial environments.
Manual bottom discharge valve
The Manual Bottom Discharge Valve is installed at the bottom outlet of storage tanks, reactors, and process vessels to ensure complete media discharge and reliable shut-off. The valve is designed to minimize dead zones, prevent material accumulation, and improve process efficiency.
Manufactured from high-quality stainless steel, carbon steel, alloy steel, or special corrosion-resistant materials, the valve is suitable for handling liquids, viscous fluids, slurries, and chemical media. Manual handwheel operation provides easy control and dependable performance without external power requirements.
Our Manual Bottom Discharge Valves are manufactured and tested according to international standards:
Manual bottom discharge valve
| Parameter | Specification |
|---|---|
| Product Name | Manual Bottom Discharge Valve |
| Nominal Size | DN25 – DN400 (1" – 16") |
| Pressure Rating | PN10 – PN40 |
| ANSI Class | Class 150 – Class 300 |
| Body Material | SS304, SS316, SS316L, Carbon Steel, Alloy Steel |
| Seat Material | PTFE, RPTFE, PPL, Metal Seat, Graphite |
| Connection Type | Flanged, Butt Weld |
| Operation | Manual Handwheel |
| Temperature Range | -29°C to +350°C |
| Leakage Standard | API 598 / ISO 5208 |
| Design Standard | DIN, ANSI, ASME, GB |
| Installation Position | Tank Bottom / Reactor Bottom |
| Applicable Media | Liquids, Slurries, Chemicals, Viscous Fluids |
Manual bottom discharge valve
Reactor discharge, corrosive chemical handling, and process vessel emptying.
Sanitary production systems, reactor discharge, and clean process applications.
Liquid ingredient handling, syrup discharge, and sanitary processing systems.
Storage tank discharge and process fluid transfer operations.
High-purity media handling and batch processing systems.
Complete drainage and residue-free discharge of process media.
Material customization plan
Customized 316L stainless steel valves forGerman chemical enterprises. Resistant tostrong corrosion, suitable for their acidicmedium transportation systems, with aservice life extended to over 8 years.
Structural optimization design
For the Saudi desert project, the valve stemsealing structure was changed to a doublebellows design to address the leakage issuein the high-temperature and dustyenvironment, and it was highly recognizedby the customers.
Interface standard adaptation
Customized API 600 standard valves for acertain company in the United States. Theflange size is fully compatible with ANSIB16.5, ensuring zero error during on-siteinstallation and reducing the constructionperiod by 30%.
