Cone valve
The Cone Valve is a specially designed flow control valve featuring a cone-shaped sealing structure, providing excellent shut-off performance, smooth flow regulation, and reliable operation under demanding working conditions. It is widely used for controlling the flow of liquids, gases, powders, and other industrial media.
With a compact structure, high sealing reliability, low maintenance requirements, and strong adaptability, the cone valve is suitable for applications requiring precise flow control, isolation, and pressure management. The optimized cone design ensures stable operation, reduced flow resistance, and extended service life.
Our cone valves are manufactured using advanced machining technology and strict quality control procedures. With complete valve industry certifications and professional engineering capabilities, we provide high-quality valve solutions for global industrial customers.
Cone valve
We provide professional OEM and ODM services to meet different industrial requirements, including:
We have a complete quality management system and full valve industry certifications, ensuring product reliability, safety, and compliance with international standards.
Parameter Specifications
| Item | Specification |
|---|---|
| Product Name | Cone Valve |
| Valve Type | Cone Type Flow Control Valve |
| Application Medium | Liquid, Gas, Powder, Slurry, Industrial Media |
| Nominal Diameter | DN15 – DN1000 (Customized Available) |
| Pressure Rating | PN10 – PN40 (Customized According to Requirements) |
| Operating Temperature | -40℃ to +300℃ (Customized Available) |
| Valve Body Material | Carbon Steel / Stainless Steel / Alloy Steel |
| Cone Material | Stainless Steel / Special Alloy / Customized |
| Sealing Material | PTFE / EPDM / NBR / Metal Seal |
| Connection Type | Flange / Thread / Welding / Customized |
| Operation Type | Manual / Pneumatic / Electric / Hydraulic |
| Flow Control | On-Off Control / Flow Regulation |
| Sealing Performance | High Reliability / Low Leakage Design |
| Flow Direction | Bidirectional or Customized |
| Surface Treatment | Anti-corrosion Coating / Polishing / Special Treatment |
| Applicable Pressure | Low Pressure to High Pressure Applications |
| Design Standard | International Valve Design Standards |
| Testing Standard | Pressure Test, Leakage Test, Performance Test |
| Certification | CE, ISO Quality System, Valve Industry Related Certifications |
| OEM Service | Available |
Industry Applications
Cone valves are widely applied in various industrial fields, including:
Material customization plan
Customized 316L stainless steel valves forGerman chemical enterprises. Resistant tostrong corrosion, suitable for their acidicmedium transportation systems, with aservice life extended to over 8 years.
Structural optimization design
For the Saudi desert project, the valve stemsealing structure was changed to a doublebellows design to address the leakage issuein the high-temperature and dustyenvironment, and it was highly recognizedby the customers.
Interface standard adaptation
Customized API 600 standard valves for acertain company in the United States. Theflange size is fully compatible with ANSIB16.5, ensuring zero error during on-siteinstallation and reducing the constructionperiod by 30%.
